System context-properties

Parent

Child

Namespace

Property

Type

PartnerInProperties

http://link.bizbrains.com/properties/partner-in

Id

Int32

Key

String

SequenceNumber

Int64

IdentificationValue

String

IdentificationQualifier

String

IdentificationValue2

String

IdentificationQualifier2

String

IdentificationValue3

String

IdentificationQualifier3

String

ProxyPartnerId

Int32

Name

String

PartnerOutProperties

http://link.bizbrains.com/properties/partner-out

Id

Int32

Key

String

SequenceNumber

Int64

IdentificationValue

String

IdentificationQualifier

String

IdentificationValue2

String

IdentificationQualifier2

String

IdentificationValue3

String

IdentificationQualifier3

String

ProxyPartnerId

Int32

Name

String

TransportOutProperties

http://link.bizbrains.com/properties/transport-out

DisplayName

String

TransportTypeId

Int32

TransportTypeKey

String

TransportOutConfigurationId

Int32

TransportOutJsonConfig

http://link.bizbrains.com/properties/transport-out/json/step-configs

TransportOutConfig

String

InitConfigurationProperties

http://link.bizbrains.com/properties/initconfiguration

InitConfigurationId

Int32

DocumentTypeId

Int32

FormatId

Int32

VariantId

Int32

VariantVersionId

Int32

FormatTypeId

Int32

SenderIdentification

String

SenderIdentificationType

String

ReceiverIdentification

String

ReceiverIdentificationType

String

DocumentNumberMacro

String

PreDisassembleInitStepId

Int32

PreDisassembleInitStepConfig

String

PostDisassembleInitStepId

Int32

PostDisassembleInitStepConfig

String

CustomDisassembleInitStepId

Int32

CustomDisassembleInitStepConfig

String

SenderPartnerId

Int32

DistributionIds

List<Int32>

ReceiverPartnerIds

List<Int32>

PartnerSystemId

[Nullable]Int32

MessageMetaDataProperties

http://link.bizbrains.com/properties/message-metadata

PayloadRequestsAcknowledgement

Boolean

Encoding

String

ContentType

String

IsControlMessage

Boolean

ItineraryProperties

http://link.bizbrains.com/properties/itinerary

FullItinerary

List<String>

CompletedItinerary

List<String>

DocumentProperties

http://link.bizbrains.com/properties/document

DocumentNumber

String

Id

Int64

DocumentGuid

Guid

ContextPropertiesGuid

[Nullable]Guid

MessageNumberIn

String

MessageNumberOut

String

MessageInFileGuid

[Nullable]Guid

MessageFilenameCdm

String

DocumentConfigInProperties

http://link.bizbrains.com/properties/document/documentconfig-in

Id

Int32

FormatId

Int32

FormatName

String

VariantId

Int32

VariantName

String

VariantVersionId

Int32

VariantVersion

String

FormatTypeId

Int32

FormatTypeName

String

FormatTypeDefaultExtension

String

DocumentConfigOutProperties

http://link.bizbrains.com/properties/document/documentconfig-out

Id

Int32

FormatId

Int32

FormatName

String

VariantId

Int32

VariantName

String

VariantVersionId

Int32

VariantVersion

String

FormatTypeId

Int32

FormatTypeName

String

FormatTypeDefaultExtension

String

DocumentTypeProperties

http://link.bizbrains.com/properties/documenttype

Id

Int32

DocumentTypeName

String

ResendProperties

http://link.bizbrains.com/properties/resend

InterchangeInId

Int64

DocumentId

Int64

ContextPropertiesFileGuid

Guid

ResendType

Bizbrains.Link.Base.Implementations.MessageProperties.PropertyContainers.ResendType

ProcessingOptions

http://link.bizbrains.com/properties/processingoptions

GenerateNewTransmissionId

Boolean

InterchangeInProperties

http://link.bizbrains.com/properties/interchange-in

ContextPropertiesGuid

[Nullable]Guid

DisassembleSystemPreOutputCount

Int32

DisassemblePreOutputCount

Int32

DisassembleOutputCount

Int32

DisassemblePostOutputCount

Int32

DisassembleSystemPostOutputCount

Int32

Filename

String

TransmissionId

String

Id

Int64

InterchangeNumber

String

PartnerSystemId

Int32

InterchangeGuid

Guid

DisplayAddress

String

InterchangeOutProperties

http://link.bizbrains.com/properties/interchange-out

Filename

String

TransmissionId

String

Id

Int64

InterchangeNumber

String

PartnerSystemId

Int32

InterchangeGuid

Guid

DisplayAddress

String

DistributionProperties

http://link.bizbrains.com/properties/distribution

Id

Int32

ExpectAcknowledgement

Boolean

BatchingProperties

http://link.bizbrains.com/properties/batching

BatchingKey

String

DocumentIds

List<Int64>

BatchingFilename

String

RetryProperties

http://link.bizbrains.com/properties/retry

RetryCount

Int32

RetryIntervalSeconds

Int32

RetryDestinationQueueChannelName

String

RetryMessageArea

String

RetryMessageAreaId

String
